K165/265 聯網型行車記錄器 | 車載視訊 | 神達數位 - 車用電子及智聯網解決方案的領導廠商

K165/K265

一體式7路攝影聯網型行車記錄器

Product	K165	K265
Platform	Qualcomm^® QCS610 Octa Core CPU, 2+6 Kryo, 2.2GHz/ 1.8GHz
OS	Android^™ 10 (non GMS)
Memory	4GB RAM/32GB Internal Storage
Storage	Dual Micro SD Slots (Support up to 512 GB/ slot)
Wireless Interface	IEEE 802.11 a/ b/ g/ n/ ac (2.4 GHz & 5 GHz) Bluetooth^® 5.0 BLE Non ADR: Qualcomm^® Internal GPS/ ADR: U-Blox NEO-M8L LTE Cat. 4
NFC	NFC: MiFare^®, FeliCa \| RFID (HF): ISO14443A&B, ISO15693
Camera	Forward: FOV: D 142.8°/ H 120.4°/ V 63.8° (±5%) Full HD 1920 x 1080 @ 30 fps (configurable)	Forward: FOV: D 142.8°/ H 120.4°/ V 63.8° (±5%) Full HD 1920 x 1080 @ 30 fps (configurable) Inward (IR): FOV: D 142.8°/ H 120.4°/ V 63.8° (±5%) Full HD 1920 x 1080 @ 30 fps (configurable)
Expandible Cameras	TVI x 4, USB x 1
Physical Interface	Dual Micro SD Slots (Support up to 1TB /Slot) Nano SIM Slot (SIM 1) and eSIM** (SIM 2) Mini USB x 1 (for Ext. Cameras), USB Type C x 1 (for de-bug) Build-in microphone x 2 Build-in Speaker x 1
Buttons	Emergency recording button for driver to manually trigger 60s recording (5 ˜ 30s before and 5 ˜ 30s after, adjustable)
Environment	-20 to +60C (-40 to +140F) Operating Temperature -20 to +70C (-40 to +158F) Operating Temperature (Under Certain Conditions) -30° to +85°C (-22° to +185°F) Storage Temperature
Certification*	CE,CB, FCC/IC, UKCA, RCM, BQB, PTCRB, AT&T, Verizon, T-Mobile, WEEE, ROHS
Dimensions	124 x 88.6 x 72mm ( 4.88 x 3.48 x 2.8'')	124 x 88.6 x 101mm ( 4.88 x 3.48 x 3.97'')
Remark	Region Dependent, *Optional
